Process flow:
Feeding of conveyor belt → Fiber optic point finding → Gathering and dividing of balls → Ball inspection → Placement of Nibao → Placement of holder → Mechanical arm upper protection detection → Unqualified kick out → Placement of holder → Pre pressing → Riveting pressing → Final inspection → Rejection of non-conforming products → Finished product discharge
Main functions:
Automatically complete the entire set of actions;
Feeding mechanism: bearing automatic feeding, cage string rod feeding;
Fiber optic point finding: Automatically find a suitable space for inserting the ball mold, ensuring that the steel ball is undamaged;
Ball distribution mechanism: plug-in ball collection, needle insertion ball distribution;
Ball distribution detection: missing ball, uneven distribution;
Upper retainer feeding: Use a string rod form for feeding, taking one retainer at a time and placing it above the product;
Upper retainer detection: fewer upper retainers, more upper retainers;
Lower retainer loading: Use a string rod form for loading, taking one retainer at a time and placing it under the product;
Riveting and pressing station: pre bending is carried out by a helical tooth mold, and then formal bending is carried out by a flat tooth mold;
Post press inspection: The bending claw height is not standard, and the cage is deformed, leaking pressure, and the cage is missing;
Equipped with positioning digital display detection and electric touch detection;
The complete machine is easy to replace, meeting the production mode of small batch and multiple varieties;
The special design of the mold that directly contacts the cage and steel ball ensures no damage to the cage and steel ball;
Equipment features:
Fiber optic vacancy finding mechanism; No injury, close the ball
Ball distributor Bull polishing: no damage ball distributor
Multiple testing: ensuring high-quality product output
Double down protection function can be added for installation.
Customizable series of error prevention functions
Overall appearance design with hood added
Customized operation direction for the entire machine, suitable for various whole line schemes
| Device model | JR-BC50 | |
| Scope of application | Bearing outer diameter 8-16mm | Bearing outer diameter 16-50mm |
| Work Efficiency | ≤4 seconds | ≤ 3.2 seconds |
| Working Voltage | 220V/50Hz/1.5A | |
| Working air pressure | ≥0.4MPa | |
| Overall dimensions | L1270×W600×H1800mm | |
