READ MOREProcess flow:
Flexibility of fiber optic selection → Imaging → Weighing → Finding points for grease injection → Flipping → Finding points for grease injection → Weighing → Fiber optic grease detection → NG product discharge → Cover sending and releasing → Pre pressing detection → Cover pressing → Post pressing detection → Flipping → Cover sending and releasing → Pre pressing detection → Cover pressing → Post pressing detection → NG product discharge → Uniform grease → OK whole column
Accuracy indicators:
Oil content+0.05g
No cover movement, no cover deformation
Variable momentum: ≤ 0.03%
Featured features:
Flexibility adopts the fiber optic ball finding method. The stepper motor drives the outer ring of the product to rotate, and the fiber optic senses the steel ball. The number of bearing rings is calculated by calculating the number of steel balls through data. Imitate manual selection flexibility and low misjudgment rate.
The dust cover detection adopts linear resistance, which is stable and reliable, and Data and information visualization can be set. Pre and post pressurization testing (with or without a cover, the pressurization cylinder does not operate; NG and non pressurization products are detected)
Industrial cameras detect small balls, small retainers, or incomplete retainers. High precision electronic scales are used to test all products that do not meet the requirements for grease injection. The data can be set and there is an automatic reset function. The machine has an electronic scale for visual observation
Window inspection and floor mounted installation of electric scales.
This machine has a humanized alarm prompt function. When the machine is out of material, full of material at the back, or malfunctions, it will be displayed in the form of a running light on the touch screen. At the same time, the alarm light will prompt different colors of alarms according to different faults.
Customizable series of error prevention functions
Overall appearance design such as installing a hood
Customized operation direction for the entire machine, suitable for various whole line schemes
Device model | JR-ZY0102 | JR-ZY0203 | JR-ZY0305 | JR-ZY0507 |
Scope of application | Bearing outer diameter 7-28mm | Bearing outer diameter 20-62mm | Bearing outer diameter 60-100mm | Bearing outer diameter 60-160mm |
Work Efficiency | ≤ 2.8 seconds | ≤ 3.5 seconds | ≤ 4.5 seconds | ≤ 7 seconds |
Working Voltage | 220V/50Hz/1.5A | |||
Working air pressure | ≥0.4MPa | |||
Overall dimensions | L1860×W700×H1800mm | L2400×W900×H1800mm | L2800×W1400×H1800mm |
